W1000F – lattice tower
H06 H09 H12 H15 H18
The 1000F tower is assembled from 3 sections. Each segment is in the shape of a triangle with a side length of 1000mm, which are connected by a flange. The mast stands in a vertical position thanks to the use of galvanized stays. There is no rope guy wires.
Construction: triangle truss with a side 1000mm (first segment of the tower) do 1000mm (top of the tower)
Segment Lenght/Weight: 6m: ~ 36[kg] 3m: ~ 18[kg].
Segment: bolted flanges
Material: aluminium EN AW-6005A T6
[PDF] LIST OF CONSTRUCTION EQUIPMENT W1000F
All structure fitting have certificates and atest that comply with European Council Directives and national legislation.
Accessories for W1000F
Aerial bracket WA1000F
The antenna bracket used allows the separation of antennas hanging on towers from the M1000F group. The distance of the individual antennas can be 20 cm. The bracket is installed to the fi35 pipe, which is available in four lengths: 0.8m, 1m, 1.5m, 2m. The set includes U-Bolt model clamps with fastenings to the structure in every place. Additional equipment with transceivers on supports ensures better safety when using the tower.
The aerial bracket WA1000F
Warranty: 24 months.
Aerial bracket WR1000F
WR1000F is a radio link support, which can be optionally mounted to the tower structure of the M1000F line, on which you can mount devices to fi60 or fi50 pipes up to a length of 1 m. The set includes clamps for mounting on any height. The installation of transceivers increases safety on tower.
The radio link bracket WR1000F
Tower final WR1000F Separation crown
Separation crown for W1000F
Warranty: 24 months
